WD Kits
A weight distribution hitch takes the tongue weight pressing down on your truck's rear axle and levers it forward and back across all the axles, so the rig rides level, the beams aim where they should, and the truck steers and brakes closer to how it does empty. The kits here run from Eaz-Lift's round-bar Elite systems up to Equal-i-zer and Fastway e2 setups with built-in 4-point sway control, plus the Reese Steadi-Flex. Nearly all are sold by weight rating, and that rating has to line up with your loaded trailer for any of it to work.
16 products
Draw-Tite Reese Steadi-Flex Trunnion Weight-Distribution Hitch Kit | 12,000 lb GTW, Built-In Sway Control
Reese Steadi-Flex Weight-Distribution Hitch Kit | 10,000 lb GTW / 1,000 lb TW, with Shank & Built-In Sway Control
Equal-i-zer 4-Point Sway Control Weight Distribution Hitch | 6,000 lb GTW, No Shank Included
Eaz-Lift Elite Weight Distribution Hitch | 1,000 lb Class, Forged Adjustable Shank
Camco Eaz-Lift Elite Weight Distribution Ball Mount Kit | For 600-1,400 lb Round Bar Systems
Eaz-Lift Replacement Weight-Distribution Spring Bar | 1,000 lb Capacity, 1-3/8" Diameter
Equal-i-zer 4-Point Sway Control Hitch | 14,000 lb WD Kit with Shank
Equal-i-zer 4-Point Sway Control Weight Distribution Hitch | 14,000 lb / 1,400 lb Tongue, No Shank
Equal-i-zer 4-Point Sway Control Weight Distribution Hitch Kit | 10,000 lb GTW, 1,000 lb TW
Equal-i-zer 4-Point Sway Control Weight Distribution Hitch | 12,000 lb / 1,200 lb Tongue, No Shank
Equal-i-zer 4-Point Sway Control Hitch | 10,000 lb WD Kit, No Shank
Fastway e2 2-Point Sway Control Trunnion Weight Distribution Hitch | 10,000 lb / 1,000 lb Tongue
Fastway e2 Trunnion Weight Distribution Hitch | 12,000 lb GTW, 1,200 lb TW, Built-In Sway Control
Fastway e2 2-Point Sway Control Trunnion Hitch | 4,500 lb WD Kit, Ball Not Included
Equal-i-zer E2 10K Round Bar Weight Distribution Hitch | Built-In Sway Control, 2-Point, 10,000 lb
Fastway e2 2-Point Sway Control Round Bar Weight Distribution Hitch | 6,000 lb, Ball Not Included
Sizing a weight distribution hitch
Tongue weight is the number that drives everything, generally 10 to 15 percent of your loaded trailer weight. A WD hitch carries a tongue-weight range and a gross trailer weight rating, and the spring bars have to fall in that window. Bars too stiff for a light trailer beat up the ride; bars too soft for a heavy one never transfer the load. Weigh the loaded rig on a scale if you can, then size from the real figure.
- Match the weight rating. These kits are rated by gross trailer weight and tongue weight: the Fastway e2 at 4,500 lb, the Equal-i-zer and Reese Steadi-Flex around 10,000 to 14,000 lb GTW with 1,000 lb tongue. Pick the range your loaded tongue weight lands in, not the trailer's dry number.
- Round bar vs. trunnion. The Eaz-Lift Elite runs round spring bars that hook underneath; the Fastway e2 and Equal-i-zer use trunnion bars seated in the sides of the head for more ground clearance and higher capacity. Trunnion is the usual pick on heavier trailers.
- Built-in sway control. The Equal-i-zer 4-point and Reese Steadi-Flex fold sway control into the head and brackets, so there's no separate friction bar to add and nothing to disconnect before you back up.
- Shank and ball, included or not. Read the fine print: the Fastway e2 kit ships without a ball, and some Equal-i-zer kits come with no shank. Confirm you're getting the drop or rise shank your receiver height needs and the ball size that fits your coupler.
- Spare and replacement parts. Spring bars and ball-mount kits wear out or change with a new trailer. Eaz-Lift sells replacement 1,000 lb round bars and round-bar ball mount kits, so you rebuild the hitch instead of replacing the whole thing.
A WD kit levels the load, but on a tall or wind-catching trailer add dedicated sway control if your hitch doesn't already include it. Round out the setup with the pins, mirrors, and safety-chain hardware in hitch accessories.
